Thunder Tiger F-75-S 4-Stroke Glow Engine

Thunder Tiger's new F-75 S engine is the perfect way to enjoy the advantage of four-stroke performance; the ability to swing a large prop, increased torque, reduced noise and improved fuel economy. Featuring a twin needle updraft carburetor, black anodized cylinder head, oversized valves and combined with a high performance silencer to give the best power-to-weight ratio possible.

Features:-

• Black cylinder head.
• Crankshaft with Ni plating to reduce corrosion.
• XC2 (extreme composite coating) cylinder liner with special criss-cross pattern etched.
• Lightened hyperutectic machined Al-Si ringed piston.
• High strength connecting rod with bushings pre-installed.
• Over-sized drive washer diameter for 13” to 18” propeller.
• Dual ball bearing supported crankshaft.
• Rubber- sealed rear bearing to reduce corrosion.
• Plain bearing supported camshaft.
• Fine polishing rocker cover.
• State of the art CNC machined components.
• Smooth manifold.
• Rear-mounted up draft and Reversible carburetor.
• Black anodized muffler included.
• Redline RF glow plug included.

Specifications:-

Displacement 12.33c.c. / .752 cu.in.
Bore 28.3 mm / 1.114 in.
Stroke 19.6 mm / 0.772 in.
Practical R.P.M. 2,300 ~ 12,000 rpm
Output 1.2 BHP / 11,000 RPM
Weight 457.2 g / 16.13 oz

Included with each engine:-

1. F-75S engine x 1 EA
2. Carburetor Assembly x 1 EA
3. Allen wrench 3mm 2.5mm 2mm 1.5mm
4. Wrench 5/5.5  12/14
5. Muffler Assembly x 1 EA
6. REDLINE RF glow plug x 1 EA  (Fitted in engine)
7. TT logo sticker x 1 EA
