RBC Rok Sportjet Kit

Rok Sportjet Designed by Luc Dietvorst and R.Bulk For 100mm Midi fan Evo edf and 6-8 cells HV6000

For 100mm Midi fan Evo edf and 6-8 cells HV6000 (2 packs 6000 3 or 4s needed)
Why a 100mm fan ?
The 100mm gives a lot of thrust
We advise the 6s Midi Fan Evo 100mm with HET 700-75-1750, or 8s hetrc edf 700-75-1400
The Rok can  be fitted with a 90mm midifan evo HET 650-68-1600  with some adjustments

The Rok  is easy to fly but not for beginners or beginner builders

The Rok is a lot of work to build , but very rewarding

In the instructions download are many 3d print files for the extra parts

A pilot for 3d print can be found here :

Full pictures and instructions download here

A flight movie here

Wingspan :1520mm
Wingarea :42dm
Length :1510mm

Our flying weight 4,2kg
2 packs  3S6000 HV
Receiver and retract voltage form the flight cells
wemotec midi fan evo 100mm with hetrc edf 700-75-1750

6 Channel , ailerons,elevator,Throttle,Retracts, flaps
,nosewheel steering,rudder
Kit Includes:
Photos and Instructions download
Decals as on the model added as a pdf so you can print them yourself
Full Size Rolled Cad Plans With All Parts Shown in color
Build steps on the drawing with many 3d explaining pictures
Vacuformed Canopy,, Outlet ducting

3D print files for cockpit ,seat , ,drop in fan system , for 6s and 8s
All wood and sheeting to make the Rok , 172 cnc cut parts ,  balsa  and ply
Spruce,ply and balsa stringers and all sheeting
There is no hardware  in the Rok like hinges and horns etc etc
Required to Complete:
Any 8 Channel Radio
Light weight Receiver:
Servos: About 13 grams metal gear 7x
wemotec midi fan evo 100mm with hetrc edf 700-75-1750
use our drop in extensions or print them yourself
Battery:3S or 4s lipo 6000ma HV 2x
Medium CA glue, large bottle
Small parts screws etc are not in kit ; a list of parts is included

Retracts from JP, Mains , Front, Controller
Struts example from JP , check for size wheels and lenght
Fan unit 100mm Wemotec  as we used
