Lyonaeec 88010 — WF-1 Light Fryer Rubber-Band Powered Airplane

Manufacturer: Lyonaeec

Product: WF-1 Light Fryer

Product number: 88010

Barcode: 4892818880105

Type: Rubber-band-powered model aircraft

Series: Light Plane

Country of origin: Japan

Release: 27 June 2012

Status: Discontinued

Packaging dimensions/weight: approximately 52.5 × 20.2 × 5.1 cm / 400 g
Kit contents and operation

Unlike the Hasegawa and Revell kits you've been cataloguing, this is intended to fly, rather than simply sit on a display shelf.

It is described as a rubber-band-powered airplane.

The basic principle is the traditional free-flight model:

propeller is driven by a wound rubber motor;

the rubber motor stores energy when twisted;

releasing the propeller allows the rubber to unwind;

the propeller produces thrust;

the lightweight airframe can therefore make a free flight.

The available catalogue record does not give a reliable individual parts count, so I would not invent one.
Manufacturer

Lyonaeec appears in surviving hobby catalogues primarily in connection with lightweight model aircraft and flying-model products.

The 88010 belongs to its Light Plane series rather than to the conventional plastic scale-model lines produced by companies such as Hasegawa, Revell or Airfix.

That distinction is useful for valuation: this is an operational flying model, so its value is affected by completeness and whether the flying mechanism can still be assembled and operated.
The real aircraft — Wright Flyer

The aircraft associated with the 1903 subject is the Wright Flyer, the aircraft developed by Wilbur and Orville Wright for their pioneering powered-flight experiments.

On 17 December 1903, at Kill Devil Hills, North Carolina, the Wright brothers achieved the first sustained, controlled powered flights by a heavier-than-air aircraft.

The first flight, piloted by Orville Wright, lasted approximately 12 seconds and covered about 120 feet.

The brothers subsequently made three additional flights that day, with the final flight, piloted by Wilbur, travelling substantially farther than the first.

The significance of the aircraft is not simply that it became airborne: the Wright brothers had developed a practical system combining:

powered propulsion;

aerodynamic control;

a lightweight structure;

pilot-operated control surfaces;

a suitable engine and propeller system.

Their experiments established the basic principles required for controlled powered flight.
Design

The 1903 Flyer was a biplane with two large wings arranged one above the other.

Unlike later aircraft, the pilot did not sit inside a conventional cockpit.

The pilot lay prone on the lower wing, reducing frontal area and allowing the pilot to operate the controls.

The aircraft had:

two wings;

twin propellers;

a forward elevator;

a rear vertical rudder;

a lightweight wooden structure;

fabric-covered flying surfaces.

The Wrights used wing-warping to control roll.

This was a crucial innovation.

Instead of using ailerons, the outer sections of the wings were twisted in opposite directions, changing their lift and causing the aircraft to roll.
Engine

The Wright brothers needed an engine that was sufficiently powerful but light enough for their aircraft.

No commercially available engine met their requirements, so they worked with their bicycle-shop mechanic Charlie Taylor to construct their own.

The resulting four-cylinder engine produced approximately 12 horsepower.

For a modern aircraft this is extremely little power, but in 1903 the combination of low weight and efficient propellers was sufficient.
Propellers

The Wrights also conducted extensive experiments with propellers.

They recognised that an aircraft propeller should be treated as a rotating wing rather than simply as a screw pushing through the air.

The 1903 Flyer therefore used two counter-rotating propellers.

The propellers were driven by chains derived from bicycle-chain technology.

This arrangement allowed the engine to be mounted relatively centrally while the propellers were positioned behind the wings.
The 1903 flights

The first successful flight occurred on 17 December 1903.

Orville's first flight covered approximately 120 feet.

The brothers continued flying throughout the day.

The fourth and final flight, made by Wilbur, covered approximately 852 feet and lasted around 59 seconds.

A gust of wind subsequently damaged the aircraft, ending the day's flying.

The machine was not rebuilt for further flights.

The surviving aircraft is preserved at the Smithsonian National Air and Space Museum in Washington, D.C., and is one of the most famous aircraft in the world.
Historical importance

The 1903 Wright Flyer represents a fundamental transition in engineering history.

Earlier experimenters had achieved gliding flight and some had produced powered aircraft that briefly left the ground.

The Wright brothers' achievement was different because their system demonstrated controlled, powered, sustained flight.

Their work was based on years of experimentation, particularly with gliders.

The 1903 aircraft was therefore the culmination of a development programme rather than an isolated invention.

The Wright brothers had already built and flown gliders in 1900, 1901 and 1902, gradually improving their understanding of lift and control.

The 1902 glider was particularly important because it incorporated an effective three-axis control system.
Why a rubber-powered model is appropriate

The Lyonaeec WF-1 is an interesting modern interpretation of this history because the original Wright Flyer itself was extraordinarily lightweight.

A rubber-powered model similarly relies on:

very low weight;

efficient propeller design;

relatively low power;

careful balance;

aerodynamic stability.

Although the model is not a scale replica in the strict museum-model sense, the basic operating principle makes it an appropriate educational representation of early powered flight.
