Hacker A20-6 XL EVO kv2500 + 44:1 97800029
Hacker A20-6 XL EVO kv2500 + 44:1 97800029 will be backordered from our supplier. Delivery will take between 3-5 working days & orders will be despatched once completed.
Description
Description
A20-6 XL EVO kv2500 + 4,4:1
Product description and features
The 8, 10 and 14-pole outrunner motors of the A20 series are available in 4 lengths (S, M, L, XL), with a voltage range of 7.2V to 12.6V. As a result, they cover a wide range of applications from the 250g indoor model up to the 1.5kg electric glider. The A20 series has double ball bearings, has a replaceable 3mm shaft and can be mounted both in front of and behind the head frame/engine mount.
The weight-optimised high-end motor A20-6 XL EVO kv2500 + 4,4:1 with a weight of only 130g is perfectly suitable for F3J models and glider models up to 1,5 kg.
The maximum screw-in depth of the fixing screws is 4.5mm.
Accessories
You will find the appropriate controller, batteries and a suitable propeller in the accessories tab.
Scope of delivery
1x A20-6 XL EVO kv2500 + 4,4:1, accessories for front and backmount, prop driver and instructions.
Drive Recommendations
| A20-6 XL EVO kv2500 + 4,4:1 | ||||||
|---|---|---|---|---|---|---|
| Item no.: 97800029 | ||||||
| Propeller | ACC 16x8 | ACC 13x8 | ||||
| LiPo | 3S | 4S | ||||
| Voltage [V] | 11,0 | 14,4 | ||||
| Current [A] | 34 | 36 | ||||
| Power [W] | 374 | 518 | ||||
| RPM | 5300 | 5700 | ||||
| Controller [A] | 40-50 | 40-50 | ||||
| Timing [°] | 10-15 | 10-15 |
||||
